Fixed High Frequency X-Ray Machine (3.5 -10kw)



Main Features

• SOFT TOUCH KEY BOARD SYSTEM with Finger touch buttons for KV increase / Decrease, mAs increase / decrease and Micro Switched for Machine ON / OFF, Stand By / Exposure.

• 200 APR programs in which KVp , Technic and mAs can be automatically selected by selecting the Body Part .

• 12 Blank APR Keys for User Defined Settings.

• Different Radiographic Settings for Child, Average and Fatty Patient.

• Different settings for AP, Lateral and Oblique positions.

• Each Key can be reprogrammed at the customer’s place as per customer requirements with an option to recall Factory Settings..

• 2 Step kVp and Single Step mAs for better Radiographic results.

• Illuminated LCD Display.

• Digital meter for Main Line voltage display for accurate exposure.

• Microprocessor Based Electronic Overload Protection for Better Tube Safety Life.

• Microprocessor Based Electronic Exposure control for accurate Exposure

• Automatic selection of Bucky with manual option.

• Exposure counter.

• Self Diagnostic ERROR Indication.

Model AE 100HF
Ratings 100mA /100kVp
Output 3.5KW-10KW (High Frequency)
mAs Microprocessor Controlled
Tube Stationary Anode / Rotating Anode
Stand Counter Balanced
Compatible Table Horizontal Bucky Table / Floating Top Table
Power Requirement Single Phase 220 V AC, 15Amp
